GOOZEEZOO 8010 8-Band 400W End-Fed Half-Wave HF Antenna
Product description
Multiband, tuner-free capability: This end-fed half-wave antenna covers eight amateur bands—10 m, 12 m, 15 m, 17 m, 20 m, 30 m, 40 m and 80 m—using a built-in 1:64 impedance transformer. It is designed to present low SWR across the supported frequencies so many operators can use it without adding an external antenna tuner.
Power handling and transformer specifics: The assembly is rated for 400 W SSB, 300 W CW and 150 W modes like FT8. The impedance transformer uses a high-performance ferrite core sized 63 × 38 × 20 mm to deliver reliable impedance transformation and to tolerate high-power operation.
Passive cooling design: The transformer and circuitry are enclosed in a vented housing that promotes air-convection cooling—cool air is drawn in at the bottom and warm air exhausts at the top—helping to prevent heat build-up during extended transmit periods.
Deployment options and usage: The antenna supports horizontal, vertical or sloped orientations, making it suitable for backyard installations, portable activations (POTA/SOTA) or emergency field use. For best performance, allow about 45 m of overall space for the wire run and keep the radiator at least 3 m clear of dense foliage and about 5 m from large metal objects.
Construction and service life: The transformer is housed in a UV-resistant, waterproof ABS enclosure and paired with heavy-gauge antenna wire and insulators for outdoor durability. Expected service life under normal outdoor conditions is roughly 3–5 years; periodic inspections every six months are recommended to check hardware, connections and the wire.
What’s included: The package typically contains the end-fed antenna wire with end insulators, the 1:64 transformer/balun in its vented ABS housing, and basic mounting cord/hardware for securing the feed point and far end. Feed and mounting details let you connect the transformer to a coax feedline and deploy the wire in the desired configuration.
Pros
- Covers eight HF bands with low SWR
- High power rating (400W SSB) and sturdy transformer
- Versatile horizontal/vertical/sloped installation
Cons
- Requires substantial space for optimal deployment
- Limited guaranteed service life (3–5 years)
- Not tuned for 160 m operation
VerdictA robust, no-tuner-ready end-fed solution for hams needing a multiband wire antenna that handles significant power. The enclosed 1:64 transformer and heavy-gauge wire provide stable impedance and consistent low SWR across the supported bands. Its passive air-convection housing helps keep the balun cool during long transmissions, and the UV-resistant, waterproof enclosure and stout wire give it dur
Reviews
-
Quantis 5/5
Does what it claims
Surprised at how well it performs. SWR is good on the advertised bands. Running 100 W now and planning an amp — chose the larger balun. The balun case has vents to allow convection cooling.
-
Rob 5/5
Sturdy all-band HF performer
Seven months in service; held up to trees, snow, wind and rain. Made European contacts on 5 W using SSB and FT8. SWR remains good from 80–10 m; verified with a NanoVNA when new and now.
-
Thomas Kilburn 5/5
Field use — check SWR and trim
Measure SWR and trim the wire for lowest readings. I ran QRP and used it for emergency field exercises, making contacts across the US and into Europe.
-
Don hall jr 5/5
Performs reliably
Has been working without problems.
-
Jorge 4/5
Under evaluation
One week of use and a few contacts so far. Currently installed about 20' up; I plan to raise it above 35'. I'll update later, but initial results are promising.
-
JudyG 5/5
Good first DX antenna
Well-built and holding its full length. From Washington state I've worked stations in Japan, Australia and throughout the US. Pretty satisfied so far.
-
Don 5/5
Excellent value and dependable DX
I've run this for six months. Initially a 20' sloper and later routed low along a wooden fence to avoid kids, it still makes worldwide contacts. Worked well on an Icom IC-7000 and Yaesu FT-710. Tunes 80–10 with low SWR using an internal tuner; 6 m tuned near 1.7:1 and produced contacts. 160 m won't tune. It has survived snow, rain, wind and hail with no issues.
-
Navyvet8192 5/5
Consistent SWR readings
Nice SWR across bands; worst was about 1.42 on 10 m. Set up as a 40° sloper with the feed end about 10' high. 73, KJ5KMC.
-
Steve Bird 5/5
Simple, effective and affordable
Started making global contacts immediately with this straightforward antenna. If you have the space, it's a solid choice.
